500W Laser Cleaning Machine Plastic Injection Molding Alum Metal Rust Remover Machine
Place of Origin | Shanghai, China |
---|---|
Brand Name | CYCJET |
Certification | SGS, FDA, CE |
Model Number | CLC500 |
Minimum Order Quantity | 1 Set |
Price | USD8500-USD10500 |
Packaging Details | Standard Export Polywood Case |
Delivery Time | 10-12 working days after we received advance payment |
Payment Terms | L/C, T/T, Western Union, Western Union, MoneyGram |
Supply Ability | 120 sets per month |

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xName | Metal Laser Cleaning Machine | Output Power | 500W |
---|---|---|---|
Laser Wavelength | 1055nm-1070nm | Scanning Width | 1-120mm, 1-60mm |
Washing Methos | Manual Type | Cooling | Water |
Warranty | 1 Year After Customer Receive The Machine | Delivery Time | 12 Working Days After We Receive Advance Payment |
Application | Painting Surface, Steel, Alum, Iron Stone, | Laser Source | MAX/JPT |
High Light | 500W Laser Cleaning Machine,Plastic Injection Molding Laser Cleaning Machine,alum metal rust remover machine |
500W Metal Laser Cleaning Machine for plastic injection molding, laser metal cleaning machine
Description of Metal Laser Cleaning Machine:
Metal Laser cleaning machine is the new generation of safe, high efficiency, energy saving, environment-friendly metal laser cleaning equipment, using new designed handheld cleaning head, friendly operation industrial touch panel and button control, combined with the advanced integrated operation software, the precision laser cleaning rust machine is assembled. It meets the cleaning requirements of complex shapes and fine positioning in the industrial processing, and achieves higher cleanliness cleaning effects and lower overall cost production benefits.
The handheld laser cleaning machine uses high-frequency and high-energy laser pulses to irradiate the surface of the object, so that the surface oil, rust or coating evaporates or peels faster, and effectively removes the surface attachment or surface coating of the cleaning object at a high speed, so as to achieve the cleaning of the object. It is characterized by no damage to the part matrix, no consumables, energy saving and environmental protection.
1 | Product Name: | 500W Metal Laser Cleaning Machine for plastic injection molding, laser metal cleaning machine |
2 | Average Output Power: | 500W |
3 | Output power Instability | <5% |
4 | Repeat Frequency | 10-50kHz (adjustable) |
5 | Max single pulse energy | 1(mJ) |
6 | Peak power | 90(kW) |
7 | Core | 30(μm) |
8 | Standard cable length | 5m |
9 | Scanning Width Range: | 1-120mm |
10 | Cleaning thickness | 1(mm) |
11 | Cleaning efficiency | 15(m2/h) |
12 | Focal length(mm) | 160/220mm replaceable |
13 | Cleaning Methods: | Manual Type |
14 | Cooling: | Air cooling / Water cooling |
15 | Laser Source Optional | MAX/JPT |
16 | Machine Capacity: | 1000w |
17 | Power Supply: | 220V / 50-60HZ |
18 | Cleaning Head Weight: | 2.5kgs |
19 | Weight: | 100kgs |
20 | Working Environment Temperature: | 5-40 degree |
Features of Laser Cleaning Machine:
- High efficiency and environmental protection, do not have any chemical pollution. The 200w fiber laser cleaning machine can create powerful laser light, remove the rust or dirty surface faster.
- Easy to operate the laser cleaning machine, no need to disassemble and transport the mold. Easy to remove the machine to any place you want, ideal for the big or heavy object which can not transport.
- Power on and use without consumables, simple operation, just power on, can be hand-held or cooperate with the robot to realize automatic cleaning
- Adjustable laser parameters, suitable for a variety of environments, better cleaning result
- The light output width can be set by software, and the cleaning is accurate than other type cleaning.
- Real-time monitoring of cleaning quality: The multi-sensor can monitoring cleaning result same time
- By adjusting other parameters, the laser beam is able to achieve the desired cleaning effect accurately and easily.
Application of Laser Cleaning Machine
- Clean the rust on metal surface
- Remove the painting from metal
- Surface oil, stain, dirt cleaning
- Surface coating removal
- Welding surface, spray surface pretreatment
- Rubber mold surface cleaning
Cleaning result of Fiber laser cleaning machine
